Mint

Mint is a testing framework for Minio object server, available as a podman image. It runs correctness, benchmarking and stress tests. Following are the SDKs/tools used in correctness tests.

• awscli • aws-sdk-go-v2 • aws-sdk-java-v2 • aws-sdk-php • aws-sdk-ruby • healthcheck • mc • minio-go • minio-java • minio-js • minio-py • s3cmd • s3select • versioning

Running Mint

Mint is run by podman run command which requires Podman to be installed. For Podman installation follow the steps here.

To run Mint with Minio Play server as test target,

After the tests are run, output is stored in /mint/log directory inside the container. To get these logs, use podman cp command. For example

Mint environment variables

Below environment variables are required to be passed to the podman container. Supported environment variables:

| Environment variable | Description | Example |

| SERVER_ENDPOINT | Endpoint of Minio server in the format HOST:PORT; for virtual style IP:PORT | play.minio.io:9000 | | ACCESS_KEY | Access key for SERVER_ENDPOINT credentials | Q3AM3UQ867SPQQA43P2F | | SECRET_KEY | Secret Key for SERVER_ENDPOINT credentials | zuf+tfteSlswRu7BJ86wekitnifILbZam1KYY3TG | | ENABLE_HTTPS | (Optional) Set 1 to indicate to use HTTPS to access SERVER_ENDPOINT. Defaults to 0 (HTTP) | 1 | | MINT_MODE | (Optional) Set mode indicating what category of tests to be run by values core, full. Defaults to core | full | | MINT_MC_VARIANT | (Optional) Select mc test variant by values mc, ec. Defaults to mc. (Using ec requires providing the ec repo in the container.) | ec | | | DOMAIN | (Optional) Value of MINIO_DOMAIN environment variable used in Minio server | myminio.com | | ENABLE_VIRTUAL_STYLE | (Optional) Set 1 to indicate virtual style access . Defaults to 0 (Path style) | 1 | | RUN_ON_FAIL | (Optional) Set 1 to indicate execute all tests independent of failures (currently implemented for minio-go and minio-java) . Defaults to 0 | 1 | | SERVER_REGION | (Optional) Set custom region for region specific tests | us-west-1 |

Test virtual style access against Minio server

To test Minio server virtual style access with Mint, follow these steps:

• Set a domain in your Minio server using environment variable MINIO_DOMAIN. For example export MINIO_DOMAIN=myminio.com. • Start Minio server. • Execute Mint against Minio server (with MINIO_DOMAIN set to myminio.com) using this command

Mint log format

All test logs are stored in /mint/log/log.json as multiple JSON document. Below is the JSON format for every entry in the log file.

| JSON field | Type | Description | Example |

| name | _string_ | Testing tool/SDK name | "aws-sdk-php" | | function | _string_ | Test function name | "getBucketLocation ( array $params = [] )" | | args | _object_ | (Optional) Key/Value map of arguments passed to test function | {"Bucket":"aws-sdk-php-bucket-20341"} | | duration | _int_ | Time taken in milliseconds to run the test | 384 | | status | _string_ | one of PASS, FAIL or NA | "PASS" | | alert | _string_ | (Optional) Alert message indicating test failure | "I/O error on create file" | | message | _string_ | (Optional) Any log message | "validating checksum of downloaded object" | | error | _string_ | Detailed error message including stack trace on status FAIL | "Error executing \"CompleteMultipartUpload\" on ... |

For Developers

Running Mint development code

After making changes to Mint source code a local podman image can be built/run by

Adding tests with new tool/SDK

Below are the steps need to be followed

• Create new app directory under build and run/core directories. • Create install.sh which does installation of required tool/SDK under app directory. • Any build and install time dependencies should be added to install-packages.list. • Build time dependencies should be added to remove-packages.list for removal to have clean Mint podman image. • Add run.sh in app directory under run/core which execute actual tests.

Test data

Tests may use pre-created data set to perform various object operations on Minio server. Below data files are available under /mint/data directory.

| File name | Size |

| datafile-0-b | 0B | | datafile-1-b | 1B | | datafile-1-kB | 1KiB | | datafile-10-kB | 10KiB | | datafile-33-kB | 33KiB | | datafile-100-kB | 100KiB | | datafile-1-MB | 1MiB | | datafile-1.03-MB | 1.03MiB | | datafile-5-MB | 5MiB | | datafile-6-MB | 6MiB | | datafile-10-MB | 10MiB | | datafile-11-MB | 11MiB | | datafile-65-MB | 65MiB | | datafile-129-MB | 129MiB |

Updating SDKs/binaries in the image

In many cases, updating the SDKs or binaries in the image is just a matter of making a commit updating the corresponding version in this repo. However, in some cases, e.g. when mc needs to be updated (the latest mc is pulled in during each mint image build), a sort of "dummy" commit is required as an image rebuild must be triggered. Note that an empty commit does not appear to trigger the image rebuild in the Docker Hub.

Description from the Docker Hub listing.
